45° Elbow – Twin Walled Pipe
45° Elbow (the maximum angle permitted under Building Regulations) to create turns in a twin wall flue system. Can also be paired to produce an offset.
This item features push-fit male and female connections and comes with a Locking Band.
Available in Stainless and black finishes, 125mm-200mm internal diameters.
Please note – As with all twin wall parts the diameter quoted is the internal diameter – The external diameter is 2 inches larger due to the surrounding insulation.
Designation number T450-N1-D-Vm-L50050-G60
- Finish: Stainless
- Inner Diameter: 150mm
- Outer Diameter: 200mm
- Height: 300mm
- Connection: Push-Fit
- Insulated: Yes (25mm Rockwool)
- Locking Band Included: Yes
- Warranty: 12yrs
- Int / Ext Grade: 316 / 304
