90° Elbow – Single Walled Flue Pipe
90° Elbow for creating right angle turns in the flue system or connecting together to create offsets. Building regulations dictate a maximum 45° turn.
This item features a push-fit male connection and we advise using High Temp. Sealant or Fire Rope (sold separately) to seal.
Available in a traditional black matt finish, 100mm-200mm internal diameters.
Designation No.: EN1856-2 T600 N1 W Vm L80100 G
- Finish: Traditional Matt
- Colour: Black
- Material: Laser-Welded Steel
- Coating: Vitreous Enamel
- Thickness: 1.2mm
- Inner Diameter: 180mm
- Effective Height: 240mm
- Effective Depth: 190mm
- Connection: Push-Fit
- Insulated: No
